Food Freeze Dryer Customer Case Studies | Real Project Data
Customer Case Library

Food Freeze Dryer Customer Case Studies

Filter by Product Category
Filter by Drying Area
SDG6000 freeze dryer chamber for freeze-dried shrimp production Kochi, India · 2025

Freeze-Dried Shrimp for Instant Noodle Toppings

SDG6000 200㎡ freeze dryer for large-scale seafood ingredient production.

Batch Load2,320 kg
Drying Time8 h
Final Moisture1.68%
Energy1.02 kWh + 1.41 kg steam/kg
View Case Study
Freeze-dried white mushroom slices case study with 100㎡ freeze dryer China · 2011

Freeze-Dried White Mushroom Slices for Soup Ingredients

SDG3000 100㎡ freeze dryer for mushroom soup ingredient production.

Batch Load1,200 kg
Drying Time11.5 h
Final Moisture2.09%
Energy1.05 kWh + 1.45 kg steam/kg
View Case Study
Freeze-dried pear slices case study with 100㎡ freeze dryer Oregon, USA · 2018

Freeze-Dried Pear Slices

SDG3000 100㎡ freeze dryer for large-scale pear slice production.

Batch Load1,200 kg
Drying Time12 h
Final Moisture2.21%
Energy1.1 kWh + 1.5 kg steam/kg
View Case Study
Freeze-dried blueberries case study with 30㎡ freeze dryer Czech Republic · 2014

Freeze-Dried Blueberries

SDG1100 30㎡ freeze dryer with perforation pretreatment for blueberry quality.

Batch Load360 kg
Drying Time13 h
Final Moisture1.97%
Energy1.8 kWh/kg
View Case Study
Freeze-dried durian case study with 30㎡ freeze dryer in Thailand Thailand · 2015

Freeze-Dried Durian

SDG1100 30㎡ freeze dryer project in Rayong, Thailand, with five customized units.

Batch Load390 kg
Drying Time13 h
Final Moisture2.09%
Energy1.73 kWh/kg
View Case Study
Freeze-dried fried rice case study with 10㎡ freeze dryer India · 2019

Freeze-Dried Fried Rice

SDG350 10㎡ freeze dryer for cooked fried rice and instant meal applications.

Batch Load125 kg
Drying Time6 h
Final Moisture1.28%
Energy1.67 kWh/kg
View Case Study
Freeze-dried pineapple slices case study with 20㎡ freeze dryer Indonesia · 2014

Freeze-Dried Pineapple Slices

SDG700 20㎡ freeze dryer for axial-cut pineapple slice production.

Batch Load244 kg
Drying Time12 h
Final Moisture2.31%
Energy1.73 kWh/kg
View Case Study
Freeze-dried radish slices case study with 3㎡ freeze dryer India · 2022

Freeze-Dried Radish Slices

SDG60 3㎡ freeze dryer for small-batch vegetable slice production.

Batch Load39.6 kg
Drying Time12 h
Final Moisture2.09%
Energy1.89 kWh/kg
View Case Study
Freeze-dried white peony root slices case study with 20㎡ freeze dryer China · 2015

Freeze-Dried White Peony Root Slices

SDG750 20㎡ freeze dryer for traditional Chinese herb slice processing.

Batch Load244 kg
Drying Time13 h
Final Moisture1.16%
Energy1.79 kWh/kg
View Case Study
Freeze-dried meat chunks case study with 10㎡ freeze dryer in Mongolia Mongolia · 2024

Freeze-Dried Meat Chunks

SDG350 10㎡ freeze dryer with 10 mm meat chunk thickness testing.

Batch Load121 kg
Drying Time12 h
Final Moisture1.49%
Energy1.77 kWh/kg
View Case Study
Freeze-dried half-cut figs case study with 10㎡ freeze dryer China · 2020

Freeze-Dried Half-Cut Figs

SDG350 10㎡ freeze dryer for half-cut figs and high-sugar fruit drying.

Batch Load136 kg
Drying Time13 h
Final Moisture1.79%
Energy1.72 kWh/kg
View Case Study
Freeze-dried apple slices case study with 20㎡ freeze dryer China · 2022

Freeze-Dried Apple Slices

SDG700 20㎡ freeze dryer with 8 mm apple slice thickness selection.

Batch Load254 kg
Drying Time12 h
Final Moisture1.97%
Energy1.82 kWh/kg
View Case Study
Freeze-dried instant tremella soup case study with 20㎡ freeze dryer China · 2017

Freeze-Dried Instant Tremella Soup

SDG700 20㎡ freeze dryer with formula optimization for instant soup blocks.

Batch Load600 kg
Drying Time20 h
Final Moisture1.94%
Energy2.3 kWh/kg
View Case Study
No matching case studies found. Try another product category or drying area.
Request a Similar Solution

Need a Similar Freeze-Drying Solution?

Please describe your requirements in as much detail as possible. Our team can help you estimate the right freeze dryer configuration and provide the following materials:

Freeze dryer quotation sheet download icon Freeze Dryer Quotation Sheet Freeze dryer manual PDF download icon Freeze Dryer Manual PDF Freeze dryer factory layout plan download icon Freeze Dryer Factory Layout Plan Freeze-dried food photos and videos download icon Freeze-Dried Food Photos & Videos

Send Your Freeze-Drying Requirement

Fill in the form below. Our team will review your product, capacity target, drying requirement, and project conditions.
