Freeze-Dried White Peony Root Slices Case Study
This case study shows how a traditional Chinese medicine processor used an SDG3000 100㎡ freeze dryer to process approximately 1,220 kg of 1.5 mm white peony root slices per batch, keep product temperature below 60°C, and complete drying in 13 hours.
1.51 kg steam/kg
Quick Facts
This white peony root slice project used real production data instead of general marketing claims. The data helps Chinese medicinal material processors evaluate batch capacity, slice thickness, product temperature control, vacuum range, cold trap capacity, final moisture, electricity use, and steam consumption.
| Location | China |
|---|---|
| Year | 2015 |
| Product | Freeze-dried white peony root slices |
| Product Type | Chinese medicinal white peony root slices |
| Equipment | SDG3000 freeze dryer |
| Drying Area | 100㎡ |
| Slice Thickness | Approx. 1.5 mm |
| Product Temperature Requirement | Below 60°C during drying |
| Loading Density | 12.2 kg/㎡ |
| Batch Loading | Approx. 1,220 kg/batch |
| Time to Dry | 13 hours |
| Final Moisture Content | 1.16% |
| Vacuum Range | 26–90 Pa |
| Condenser Capacity | 2 kg water/㎡/hour |
| Total Condenser Capacity | Approx. 200 kg water/hour |
| Energy Consumption | 1.12 kWh electricity + 1.51 kg steam/kg raw material |
| Estimated Batch Energy Use | Approx. 1,366.4 kWh electricity + 1,842.2 kg steam |
Industrial Freeze-Dried White Peony Root Slice Production
In 2015, a traditional Chinese medicine processor in China used an SDG3000 100㎡ industrial freeze dryer to produce freeze-dried white peony root slices for Chinese medicinal material processing.
The product was Chinese medicinal white peony root slices. Compared with ordinary fruit or vegetable products, medicinal root slices require careful drying control because final moisture, product temperature, appearance, structure, and storage stability all affect product quality.
For this project, white peony root slices were cut to approximately 1.5 mm thickness and loaded at 12.2 kg per square meter. With a total drying area of 100㎡, the batch loading capacity reached approximately 1,220 kg per batch.
The drying process was controlled to keep the product temperature below 60°C. The drying cycle was completed in approximately 13 hours, and the final moisture content reached 1.16%.
This calculation helps buyers understand real production capacity. Drying area alone is not enough; loading density, slice thickness, temperature control, and drying time must be evaluated together.
The Challenge: Drying 1.5 mm White Peony Root Slices Below 60°C
White peony root slices require careful drying control. If the process is unstable, the product may show uneven moisture, poor appearance, or inconsistent batch quality.
1.5 mm Slice Thickness
Thin slicing helped improve drying uniformity, but it also required stable loading and careful process control.
Below 60°C Product Temperature
The customer required product temperature control during drying to reduce excessive heat exposure.
Low Final Moisture
The final moisture content reached 1.16%, supporting storage stability and packaging.
Vacuum Stability
The drying process operated within a 26–90 Pa vacuum range.
Cold Trap Capacity
The condenser capacity was designed at 2 kg water/㎡/hour.
Energy Control
The energy consumption was 1.12 kWh electricity and 1.51 kg steam per kg of raw material.
SDG3000 100㎡ Freeze Dryer
The SDG3000 freeze dryer was selected to support industrial-scale Chinese medicinal material processing with stable vacuum control, reliable cold trap capacity, controlled heat input, and predictable drying results.
- 100㎡ drying area for industrial production
- 1.5 mm Chinese medicinal white peony root slices
- Product temperature controlled below 60°C during drying
- 12.2 kg/㎡ loading density and approx. 1,220 kg per batch
- 26–90 Pa vacuum range during drying
- 13-hour drying cycle with 1.16% final moisture
- 1.12 kWh electricity + 1.51 kg steam per kg raw material
Real Drying Data for White Peony Root Slices
This section gives buyers practical reference data. It shows how slice thickness, temperature control, loading density, vacuum range, cold trap capacity, final moisture, electricity use, and steam consumption affect actual production performance.
In this project, the SDG3000 processed about 1,220 kg of 1.5 mm white peony root slices per batch. The drying cycle was completed in 13 hours, and the final moisture content reached 1.16%.
| Product | Chinese medicinal white peony root slices |
|---|---|
| Slice Thickness | Approx. 1.5 mm |
| Product Temperature | Below 60°C during drying |
| Fresh Material Loading | 12.2 kg/㎡ |
| Total Batch Load | Approx. 1,220 kg/batch |
| Vacuum Range | 26–90 Pa |
| Condenser Capacity | 2 kg water/㎡/hour |
| Total Condenser Capacity | Approx. 200 kg water/hour |
| Final Moisture | 1.16% |
| Energy Consumption | 1.12 kWh electricity + 1.51 kg steam/kg raw material |
| Drying Time | 13 hours |
Production Result: 13-Hour Drying Cycle
The SDG3000 100㎡ freeze dryer completed the white peony root slice drying process in approximately 13 hours while keeping the product temperature below 60°C. The final moisture content reached 1.16%.
1,842.2 kg steam Estimated batch energy use
Why These Data Points Matter
For Chinese medicinal material processors, real production data is more useful than general machine descriptions. These parameters help estimate output, freeze dryer cost, and equipment suitability.
1. Slice Thickness
The product was cut to approximately 1.5 mm thickness. Thin slices can improve drying uniformity, but buyers still need to evaluate loading density, drying time, final moisture, and product quality together.
2. Temperature Control
The customer required the product temperature to remain below 60°C during drying. This helped reduce excessive heat exposure and supported stable quality for Chinese medicinal material processing.
3. Energy Consumption
The energy consumption was 1.12 kWh electricity and 1.51 kg steam per kg of raw material. Based on 1,220 kg per batch, the estimated batch energy use was about 1,366.4 kWh electricity and 1,842.2 kg steam per batch.
What Chinese Medicine Manufacturers Can Learn from This Case
This China freeze-dried white peony root slices project shows that medicinal material freeze-drying equipment should be evaluated by real drying performance, process control, cold trap capacity, electricity use, and steam consumption.
Product Form Matters
White peony root slices dry differently from fruit slices, cooked rice, tropical fruits, or leafy herbs. Slice thickness and tissue structure should be tested.
Temperature Control Matters
For Chinese medicinal material processing, product temperature control can be as important as drying time and final moisture.
Ask for Real Drying Data
Batch load, slice thickness, product temperature, final moisture, vacuum range, condenser capacity, electricity use, and steam consumption provide more value than general supplier claims.
Match Machine Size to Production Stage
A 100㎡ industrial freeze dryer can be a practical choice for industrial Chinese medicinal material processing.
