Freeze-Dried Mushroom Soup Ingredients Case Study
This case study shows how a Chinese food processor used an SDG3000 100㎡ freeze dryer to process approximately 1,200 kg of white mushroom slices per batch for mushroom soup ingredients and complete drying in 11.5 hours.
Quick Facts
This mushroom soup ingredient project used real production data instead of general marketing claims. The data helps food processors evaluate batch capacity, drying time, vacuum range, cold trap capacity, final moisture, rehydration needs, electricity consumption, steam consumption, and operating cost.
| Location | China |
|---|---|
| Year | 2011 |
| Product | Freeze-dried mushrooms |
| Product Type | White mushroom slices |
| Final Application | Mushroom soup ingredients |
| Equipment | SDG3000 freeze dryer |
| Drying Area | 100㎡ |
| Loading Density | 12 kg/㎡ |
| Batch Loading | Approx. 1,200 kg/batch |
| Time to Dry | 11.5 hours |
| Final Moisture Content | 2.09% |
| Vacuum Range | 26–93 Pa |
| Condenser Capacity | 2 kg water/㎡/hour |
| Total Condenser Capacity | Approx. 200 kg water/hour |
| Electricity Consumption | 1.05 kWh/kg raw material |
| Steam Consumption | 1.45 kg steam/kg raw material |
| Estimated Batch Electricity Use | Approx. 1,260 kWh |
| Estimated Batch Steam Use | Approx. 1,740 kg steam |
Commercial Freeze-Dried Mushroom Soup Ingredient Production
In 2011, a food processing customer in China used an SDG3000 100㎡ commercial freeze dryer to produce freeze-dried white mushroom slices as mushroom soup ingredients for instant soup and prepared food processing.
Because the final product was used in mushroom soup, the customer needed more than low moisture. The mushroom slices also needed good shape retention, clean appearance, suitable texture, and reliable rehydration performance after being added to hot water or soup.
For this project, white mushroom slices were loaded at 12 kg per square meter. With a total drying area of 100㎡, the batch loading capacity reached approximately 1,200 kg per batch.
The drying cycle was completed in approximately 11.5 hours, and the final moisture content reached 2.09%. The project used approximately 1.05 kWh electricity and 1.45 kg steam per kg of raw material.
This calculation helps buyers understand real production capacity. Drying area alone is not enough; loading density, rehydration performance, cold trap capacity, drying time, electricity use per kg raw material, and steam consumption per kg raw material must be evaluated together.
The Challenge: Producing Mushroom Soup Ingredients at Large Batch Scale
White mushroom slices are porous and suitable for freeze-drying, but large-batch production still requires stable vacuum control, sufficient condenser capacity, consistent final moisture, and clear utility consumption data.
Soup Ingredient Quality
The mushroom slices needed good shape, color, and texture for instant mushroom soup applications.
Rehydration Performance
The product needed to restore well after being added to hot water or prepared soup.
Large Batch Load
The system processed approximately 1,200 kg of fresh white mushroom slices per batch.
Vacuum Stability
The drying process operated within a 26–93 Pa vacuum range.
Cold Trap Capacity
The condenser capacity was designed at 2 kg water/㎡/hour, or about 200 kg water/hour in total.
Energy and Steam Control
The project used 1.05 kWh electricity and 1.45 kg steam per kg of raw material.
SDG3000 100㎡ Freeze Dryer
The SDG3000 freeze dryer was selected to support large-scale mushroom soup ingredient production with stable vacuum control, strong water vapor capture capacity, steam-assisted heating, and predictable batch performance.
- 100㎡ drying area for large-scale food ingredient production
- White mushroom slices used as mushroom soup ingredients
- 12 kg/㎡ loading density and approx. 1,200 kg per batch
- 26–93 Pa vacuum range during drying
- 2 kg water/㎡/hour condenser capture capacity
- 11.5-hour drying cycle with 2.09% final moisture
- 1.05 kWh electricity and 1.45 kg steam per kg raw material
Real Drying Data for White Mushroom Soup Ingredients
This section gives buyers practical reference data. It shows how loading density, vacuum control, cold trap capacity, final moisture, rehydration requirements, electricity use per kg raw material, and steam consumption per kg raw material affect actual production performance.
In this project, the SDG3000 processed about 1,200 kg of white mushroom slices per batch. The drying cycle was completed in 11.5 hours, and the final moisture content reached 2.09%.
| Product | White mushroom slices |
|---|---|
| Final Application | Mushroom soup ingredients |
| Fresh Material Loading | 12 kg/㎡ |
| Total Batch Load | Approx. 1,200 kg/batch |
| Vacuum Range | 26–93 Pa |
| Condenser Capacity | 2 kg water/㎡/hour |
| Total Condenser Capacity | Approx. 200 kg water/hour |
| Final Moisture | 2.09% |
| Electricity Consumption | 1.05 kWh/kg raw material |
| Steam Consumption | 1.45 kg steam/kg raw material |
| Drying Time | 11.5 hours |
Production Result: 11.5-Hour Drying Cycle
The SDG3000 100㎡ freeze dryer completed the white mushroom slice drying process in approximately 11.5 hours. The final moisture content reached 2.09%.
Why These Data Points Matter
For mushroom soup ingredient processors, real production data is more useful than general machine descriptions. These parameters help estimate output, freeze dryer cost, and equipment suitability.
1. Application Matters
The white mushroom slices were used as mushroom soup ingredients. Therefore, shape retention, clean appearance, texture, and rehydration performance were important quality indicators.
2. Condenser Capacity
The total condenser capacity was approximately 200 kg water/hour. For a 100㎡ freeze dryer, cold trap capacity affects vacuum stability, drying speed, and batch repeatability.
3. Electricity and Steam
The process used approximately 1.05 kWh electricity and 1.45 kg steam per kg of raw material. Based on 1,200 kg per batch, the estimated electricity use was about 1,260 kWh per batch, and the estimated steam use was about 1,740 kg per batch.
What Soup Ingredient Processors Can Learn from This Case
This China freeze-dried mushroom soup ingredient project shows that large food freeze dryers should be evaluated by real drying performance, application needs, rehydration quality, electricity consumption, steam consumption, and total operating cost.
Rehydration Performance Matters
For mushroom soup ingredients, the final product should restore well after being added to hot water or soup.
Ask for Real Drying Data
Batch load, final moisture, vacuum range, condenser capacity, electricity use per kg raw material, and steam use per kg raw material provide more value than general supplier claims.
Check Cold Trap Capacity
Large freeze dryers must have enough condenser capacity to handle water vapor load and maintain stable vacuum during drying.
Compare Electricity and Steam
For large food freeze dryers, steam-assisted heating can be important for estimating operating cost and production planning.
